Clear Quartz Glass Tube Low OH UV For UV Germicidal Field

  • Clear Quartz Glass Tube Low OH UV For UV Germicidal Field
  • Clear Quartz Glass Tube Low OH UV For UV Germicidal Field
  • Clear Quartz Glass Tube Low OH UV For UV Germicidal Field
Place of Origin China
Brand Name ZCQ
Certification SGS
Model Number ZCQ
Minimum Order Quantity 1pc
Price USD 1 to 100 /pcs
Packaging Details Wooden box
Delivery Time 5-10 work day
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 10000000pcs/day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Factory Price Low-OH Content Less Than 5 Ppm UV Quartz Silca Glass Tube Material Quartz Glass
Color Clear Length 10-300mm
OD 23mm 11mm Long-time Use Temperature 1100℃
Softening Point 1683℃ Annealing Point 1210℃
Service Customizable MOQ 10
High Light

Clear Quartz Glass Tube

,

UV Germicidal Field Quartz Glass Tube

,

Quartz Tube For UV Lamp
Leave a Message
Product Description

Factory Price Low-OH Content Less Than 5 Ppm UV Quartz Glass Tube



The low-OH UV quartz silica glass tube is used for UV Germicidal field.
After ordinary quartz tube undergoes dehydroxylation treatment, its hydroxyl content will be greatly reduced. The reason for dehydroxylation is that the high temperature of the UV lamp will penetrate the -OH in the quartz glass into the lamp tube when it is working, and it will decompose under the action of the arc, thereby oxidizing and contaminating the electrode and mercury in the lamp tube, reducing the lamp tube Service life. So low hydroxyl content in quartz tube is very important in UV Germicidal application. After the quartz tube undergoes dehydroxylation treatment, the hydroxyl content is below 10 ppm, and can even reach 5 ppm or 2 ppm.



Quartz glass tube
Parameter Diameter Tolerance Unit
Length <=2000 +/-0.1~5 mm
OD 6~300 +/-0.1~5
ID >=0.5 +/-0.1~5
Material Quartz glass, borosilicate glass, and other materials
Specification Other dimensions and tolerances can be manufactured according to customer requirements

Clear Quartz Glass Tube Low OH UV For UV Germicidal Field 0

Clear Quartz Glass Tube Low OH UV For UV Germicidal Field 1

Rich experience in quartz glass industry

We have more than 25 years industry experience in quartz glass processing. We specialize in quartz glass capillary tubes and rods, quartz glass substrates, CNC machined quartz, and quartz instruments etc. According to product application, we have good grasp of material properties and adapt the proper material into product application.



Strong technical force in processing and application

Beijing Zhong Cheng Quartz Glass Co., Ltd(ZCQ) is a high-tech manufacturer specializing in the production and customization of quartz glass products and optical glass products. We has excellent technical strength, strong innovation ability and stable product quality. Our processing method is rich, drawing of glass, cold and thermal processing, micro size machining, high precision and difficulty process, combination of multiple processing methods, which guarantee that our product is excellent in all aspects.



Integrity and Quality Assurance

We are well known in quartz glass industry. Quality is the lifeline of enterprise survival and development. Integrity is the source of enterprise reputation, the foundation of standing and the foundation of development. Through unremitting efforts and continuous improvement, we have created a good manufacturing platform of optical glass for customers.

Clear Quartz Glass Tube Low OH UV For UV Germicidal Field 2



Clear Quartz Glass Tube Low OH UV For UV Germicidal Field 3
